Especificaciones

Características

  • Full GPON bandwidth access: 2.5Gbps
    downstream & 1.25Gbps upstream
  • IP video through data port
  • VoIP voice service
  • Router function
  • IEEE 802.11n(2×2) 2.4GHz WLAN (PMG5323-
    20A only)
  • USB host
  • RF Video Overlay
  • CLI & Web GUI for management
  • 1K MAC
  • MAC limit

Interfaz

  • One SC/APC connector
    – L Wavelength: 1310nm downstream and
    1490nm upstream for data transmit and
    receive, 1550nm Downstream for RF Video
    – 28dB optical loss budget (Class B+)
  • Four RJ-45 connectors for 10/100/1000 BASET/TX
  • Two RJ-11 connectors for FXS
  • Two USB 2.0
  • One power button
  • One reset button
  • One WPS button (PMG5323-20A only)
  • One power jack for 12V DC input
  • One F type connector for analog TV
  • RF spec.
    Optical Input Power: -8 ~ 0 dBm
    – RF Bandwidth Range: 40 ~ 870 MHz
    – RF Output Power Level: typical 80 dBuV@-
    8dBm ~ 0dBm of Optical Input; OMI=4.0%
    Per channel
    – Flatness: +/-2dB in 40~870MHz@full AGC
    mode
    – RF Impendence: 75 ohm
    – CNR/CSO/CTB

Estándar compatible

  • ITU-T G.984.1, 984.2, 984.3, 984.4
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1D
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x

Entorno operativo

  •  Operating Temperature: 0~40°C
  • Operating Humidity: 10%~90% (noncondensed)

Requisitos de energía

  • Power: 12V DC / 2.0A max input

Calidad de servicio

  • VLAN translation
  • VLAN stacking (bridge mode only)
  • Strict Priority & Weighted Round-Robin Priority
  • Multicast IGMP filtering & snooping
  • IGMP proxy
  • Rate limit

VoIP

  • SIP v2 (RFC3261)
  • CODECS: G.711, G.726, G.729
  • T.38 FAX Relay
  • IGMP proxy

Router

  • PPPoE
  • IPoE
  • Packet filtering
  • NAT/NAPT
  • DNS proxy
  • Dynamic DNS
  • Static Route
  • RIP V1/V2
  • DHCP server/client

Seguridad

  • Broadcast storm protection for LAN port
  • IEEE 802.1x WiFi authentication
  • AES-128 Encryption
  • Firewall
  • DoS
  • DMZ
  • VPN pass though
    – L2TP
    – IPSec

WLAN (PMG5323-B20A only)

  • IEEE 802.11 b/g/n
  • Frequency band: 2.400~2.4835GHz
  • Operating Channels: 1~13 channels
  • WEP, SSID, WPA, WPA2
  • WPS
  • VLAN SSID binding
  • MAC access/deny list

Gestión

  • Remote control from OMCI
  • TR-069
  • Remote software upgrade
  • CLI
  • WEB GUI

Especificación física

  • Dimension(WxDxH)(mm/in.): 208 x 148 x 42 /
    8.19 x 5.83 x 1.65
